Automatic Wall Cement Plastering Machine

A wall plastering machine,automatic wall plastering machine for sale is a specialized device designed to automate the process of applying plaster to walls, ceilings, and other surfaces in construction projects. These machines significantly enhance the efficiency, speed, and quality of plaster application compared to manual methods. Our mortar pump operating system is equipped with wireless remote control and panel control, which can be switched between each other.
Send Inquiry
Product Introduction

Our automatic wall cement plastering machine is a high-efficiency device used for automatically applying plaster (a mixture of cement, sand, and water) to walls and ceilings in construction and renovation projects. This machine significantly speeds up the plastering process, reduces labor costs, and ensures a more consistent and uniform finish compared to manual plastering.

These machines are widely used in commercial and residential building projects, especially for larger surfaces where traditional plastering methods would be too time-consuming or labor-intensive.



How an Automatic Wall Cement Plastering Machine Works

An automatic wall cement plastering machine operates by mechanically applying a layer of plaster to a wall surface. The process is typically divided into several key stages: mixing, pumping, spraying, and finishing.



Key Features of Automatic Wall Cement Plastering Machines:

Automated Operation:

These machines use advanced technology to automate the mixing, application, and finishing of cement plaster, minimizing manual labor.

High Efficiency:

Capable of covering large surface areas quickly, automatic plastering machines can significantly reduce the time required for plastering compared to manual methods.

Uniform Application:

The machines ensure consistent thickness and smoothness of the plaster, resulting in a high-quality finish that may be difficult to achieve with manual plastering.

Adjustable Settings:

Many models come with adjustable speed and thickness settings, allowing operators to customize the application based on project requirements.

Lightweight and Portable:

Most automatic plastering machines are designed to be lightweight and portable, making them easy to move around job sites.



Product parameter(specification)

MODEL: SR70U/V6
Max theoretic output 0.7m³/h
Max theoretic pumping pressure 3Mpa
Hydraulic system Double pump & double circuit opening
Main oil pump displacement 80ml/r(kawasaki)
Power supply Electic Motor
Voltage 380V
Engine power 4.4KW
Distribution valve type S pipe valve
Cement mortar conveying cylinder bore/stroke /
Oil tank volume 200L
Max aggregate size 8mm
Mix Hopper Volume 115L
Feeding height 700mm
Air cpmpressment displacement & pressure 300L/min,8Bar
Max theoretic delivery vertical distance 20m
Max theoretic delivery horizontal distance 40m
Operation style wired or wireless remote control
The radiator cooling type Air cooling system
Hydraulic pump type Ram pump
Outer dimensions(L*W*H) 2130×630×850mm
Total weight 150 kg



Product application:

Residential Construction:

Ideal for plastering walls and ceilings in new homes or renovations, ensuring a smooth and professional finish.

Commercial Projects:

Suitable for large-scale commercial buildings, where efficiency and quality are crucial for meeting project deadlines.

Industrial Applications:

Used in factories and warehouses for plastering walls, providing a durable and smooth finish that meets industry standards.

Repair Work:

Effective for patching and repairing existing walls, ensuring a consistent appearance throughout the structure.

03



Product details:

01



Product work video:
