Stationary Concrete Pump For Sale

Saner HBT40-11-55S is a high-performance electric stationary concrete pump designed for long-distance and high-pressure concrete delivery. Powered by a 55kW electric motor and a double-circuit hydraulic system, it provides stable and reliable pumping performance for high-rise buildings, tunnels, bridges, and infrastructure projects.





High-Pressure Pumping Capacity: Engineered for 11MPa maximum output pressure, facilitating smooth concrete delivery across deep foundations and tall structures.

Smart Pressure Switching: Features a one-touch high and low pressure shifting mechanism to adapt instantly to changing job site delivery heights.

Anti-Blockage Reverse Action: Integrates a rapid reverse pumping function to relieve line pressure and clear potential clogs quickly.

Durable S-Pipe Valve Assembly: Equipped with an automatic wear-compensation structure to ensure long-term sealing stability under heavy loads.

Tungsten Alloy Wear Components: Utilizes heavy-duty spectacle plates and cutting rings built to withstand high abrasive wear and reduce maintenance frequency.

Genuine Kawasaki Hydraulics: Driven by a premium Kawasaki 260ml/r main pump within a dual-circuit open system for maximum volumetric efficiency.



MODEL: HBT40-11-55S
Max theoretic output					40m³/h
Max concrete pumping pressure					11Mpa
High and low valtage switchover					Yes
Hydraulic system					Double pump & double circuit opening
Main oil pump discharge					260ml/r(kawasaki)
Hydraulic system pressure					32Mpa
Power supply					Electric motor
Voltage					380V
Motor power					55KW
Motor speed					1475r/min
Distribution valve type					S pipe valve
Concrete conveying cylinder bore/stroke					Ф200/1650mm
Oil cylinder bore/stroke					Ф125/1650mm
Max aggregate size					40mm
Hopper Volume					0.6m³
Feeding height					1450mm
Max delivery vertical distance					110m
Max delivery horizontal distance					330m
Concrete slump					160-230mm
Hydraulic oil tank volume					420L
The radiator cooling type					Air cooling system
Hydraulic pump type					Ram pump
Outer dimensions(L*W*H)					5500×2150×2800mm
Total weight					4500 kg





The HBT40-11-55S operates via a dual-cylinder hydraulic piston arrangement. Driven by the Kawasaki main pump, the concrete pistons reciprocate in opposition: one cylinder suctions material from the charging hopper while the alternate cylinder forces concrete through the swinging S-pipe valve into the pipeline. Upon completion of each stroke, the S-pipe shifts position synchronously, creating an uninterrupted, continuous flow of concrete through the distribution system.





CE Certification: Fully compliant with European safety, health, and environmental compliance directives for international machinery deployment.

ISO 9001 Quality Management System: Oversees raw material verification, precision component machining, and final production testing.

Factory Performance Verification: Every unit undergoes rigorous hydraulic leak testing, electric circuit simulation, and a full-load pumping test before packaging.





To accommodate diverse international project requirements, Saner offers comprehensive tailoring:



Custom Electrical Configurations: Motor windings and control panels adjusted to match local regional voltages, frequencies, and safety codes.



Chassis and Towing Adaptations: Customized frame structures built for stationary placement or job-site relocation requirements.





Q: What is the typical operational lifespan of the wear plates and cutting rings?

A: High-strength tungsten alloy components typically last between 20,000 to 30,000 cubic meters depending on concrete aggregate abrasiveness.



Q: Can this pump operate safely in extreme tropical or high-temperature environments?

A: Yes, the integrated high-capacity air cooling system and industrial-grade hydraulic fluid reservoir maintain stable oil temperatures in high-ambient climates.



Q: What is the recommended generator size if grid power is unavailable on site?

A: A minimum 100kW to 120kW diesel generator is recommended to ensure stable startup surge current and continuous full-load operation for the 55kW motor.



Q: How is the concrete delivery pipeline connected to the pump discharge outlet?

A: The machine features a standard high-pressure outlet flange secured with quick-release couplings and heavy-duty clamp bolts for rapid pipeline assembly.



Q: Are replacement electrical components standard and easy to source locally?

A: Yes, Saner utilizes internationally recognized electrical switchgear and relay brands to ensure straightforward local compatibility and maintenance.



Q: What maintenance is required for the hydraulic oil system?

A: Routine maintenance involves monitoring oil cleanliness, cleaning or replacing filter elements every 500 operating hours, and checking fluid levels regularly.



Q: Does Saner provide on-site commissioning engineers for large overseas projects?

A: Yes, experienced field engineers can be dispatched internationally to oversee complex installation, pipeline pressure testing, and operator training.



Q: What is the lead time for standard machine production and shipping?

A: Standard configurations are typically ready for dispatch within 15 to 25 business days following order confirmation and deposit receipt.



Q: What safety protection systems are built into the electrical control cabinet?

A: The system includes phase-loss protection, overload breakers, short-circuit defense, emergency stop switches, and hydraulic oil temperature alarms.
