Mortar Spraying Machine Manufacturers

Name: China Mortar Spraying Machine Manufacturers Manufacturers Suppliers Factory - Good Price - Saner Heavy Industry
Brand: SRZG
SKU: 224818505

SRZG: Your Professional fastest cement plaster spray machine/Mortar Spraying Machine manufacturers! Hunan Saner Heavy Industry Technology Development Co.,LTD. was founded in 2010. We supply a wide range of products, as concrete pump, tunnel wet concrete sprayer machines, mortar spraying machines, concrete conveyor pump.

Send Inquiry

Product Introduction

SRZG: Your Professional mortar spraying machine manufacturers!

Hunan Saner Heavy Industry Technology Development Co.,LTD. was founded in 2010. We supply a wide range of products, as concrete pump, tunnel wet concrete sprayer machines, mortar spraying machines, concrete conveyor pump, concrete mixer and pump machines, soil hydro seeding machines.

MODEL: SR70U/V6
Max theoretic output					0.7m³/h
Max theoretic pumping pressure					3Mpa
Hydraulic system					Double pump & double circuit opening
Main oil pump displacement					80ml/r(kawasaki)
Power supply					Electic Motor
Voltage					380V
Engine power					4.4KW
Distribution valve type					S pipe valve
Cement mortar conveying cylinder bore/stroke					/
Oil tank volume					200L
Max aggregate size					8mm
Mix Hopper Volume					115L
Feeding height					700mm
Air cpmpressment displacement & pressure					300L/min,8Bar
Max theoretic delivery vertical distance					20m
Max theoretic delivery horizontal distance					40m
Operation style					wired or wireless remote control
The radiator cooling type					Air cooling system
Hydraulic pump type					Ram pump
Outer dimensions(LWH)					2130×630×850mm
Total weight					150 kg

Experienced Team

Established a group of highly skilled after-sales service teams, including experienced engineers and senior technicians. We also gain multiply national invention patents.

Good Service

Our engineers also can serve abroad and 1-year warranty for any machine purchased from us. Moreover, we can offer training about how to use and maintenance with the machine.

Quality Assurance

We perform strictly according to the ISO9001 quality system in the whole process.

Reasonable Price

We offer competitive price to achieve win-win.

Mortar Spraying Machine For Sale Display

Cement Mortar Pump

Our economical Cement Mortar Pump is called "Joint Construction Artifact" in the construction mortar spraying industry. The machine has a small size, light weight, and convenient positioning, so it can be lifted to the working surface for construction.

Building Plaster Machine

The Building Plaster Machine is suitable for the grouting work of a variety of concrete slurries. This machine streamlines the process of plastering or rendering by replacing manual labor with an automated system, increasing efficiency and productivity in construction and renovation projects.

Electric Cement Mortar Spraying Machine

The Electric Cement Mortar Spraying Machine is suitable for the grouting work of a variety of concrete slurries. It can be widely used for grouting and backfilling grouting for roads, tunnel construction, urban rails, underground caverns of hydropower plants, etc.

Mortar Screw Pump

The Mortar Screw Pump for sale is also called a wall plastering machine, mortar spray machine, or mortar plaster machine. It is easy to operate and move, can spray freely, shortens the construction period, and saves expenses.

Portable Diesel Cement Mortar Pump

The mortar spraying machine is widely used in the spraying and plastering mortar works of interior and exterior walls, thermal insulation mortar, plastic runway and gypsum mortar.

Mortar Plaster Machine

The cement mortar wall spraying machine is widely used in the construction industry because it's high efficiency, the surface of the spraying is fine and smooth, the strong adhesion and the small coating loss.

Mortar Grout Pump

Our mortar spraying machine is suitable for all kinds of mortar spraying and conveying construction operations.

Mortar Plastering Machine

Our economical small mortar pump, which was independently developed by us, is called "Joint Construction Artifact" in the construction mortar spraying industry.

Diesel Mortar Spraying Machine

The quality of the project is guaranteed, the machine flow is large, the pressure is high, avoiding the troubles and losses caused by problems such as quality, construction period and wages.

Mortar Plastering Pump

Mortar Plastering Pump is a mechanical equipment used for wall and floor construction. It is mainly used for the transmission and spraying of dry mortar, and can automatically complete the mixing, transportation, spraying and other tasks of mortar.

Mortar Pump

The mortar pump is suitable for constructions of indoor and outdoor wall spraying, cement mortar grouting, bridge grouting and waterproof surface spraying, fireproof materials spraying, ceiling spraying, wall spraying, paint spraying, garden spraying, embossing effect coating spraying, handicraft spraying, etc.

Mortar Hand Pump

The Mortar Hand Pump is a hand-operated mixing pump that easily delivers your mixture to where it's needed. It is driven by manual operation and does not require electrical or pneumatic sources. Therefore, it not only ensures the uniformity and stickiness of the mixture but is also convenient.

Introduction to Mortar Spraying Machine

The Mortar Spraying Machine is adaptable to spraying putty powder, paint, emulsion paint, real stone paint, cement mortar, dry mortar, insulation mortar, waterproof materials, fireproof materials, heat insulation materials, sound-absorbing materials, and other water-soluble materials. It is simple to operate, can shorten the construction period, and saves the expenditure of the rack material costs.

Advantages of Mortar Spraying Machine

Reduce the Construction Cost
One of the characteristics of the Mortar sprayer compared with the conventional powder wall machine is that it greatly reduces the construction cost because it reduces floor ash in the construction process. The construction process is more water-saving and material-saving, which can reduce its construction cost by more than 20%.

Guaranteed Project Quality
The quality of the project is guaranteed. The main disadvantage of the artificial powder wall and the powder wall machine is that the adhesion between the mortar and the wall and the compactness of the mortar are not enough. The machine has a large flow and high pressure, and the mortar density far exceeds the national standard. It avoids troubles and losses caused by quality, construction period, wages, and other issues.

Enhanced Safety
By eliminating the need for workers to manually handle heavy mortar loads and climb scaffolding, the use of a mortar spraying machine reduces the risk of accidents and injuries on construction sites.

High Construction Efficiency
The efficiency in the construction process is very high, and one device can easily complete 150 square meters of spraying per hour. If you work eight times a day, you can reach a thousand square feet of construction requirements.

Application of Mortar Spraying Machine

Masonry Construction

The primary application of the machine is in the construction of brick and stone walls, where they are used to apply the mortar that bonds the individual units together.

Plastering & Rendering

The machine can also be used to apply plaster or render to internal and external walls, providing a smooth, uniform finish that is both aesthetically pleasing and functional.

Grouting

In projects that require the filling of gaps or voids, such as in tunnel construction or soil stabilization, mortar spraying machines can be used to inject grout into the required areas.

Repair & Restoration

It can be used to apply repair mortar for the restoration of damaged or deteriorated structures, such as bridges, tunnels, and historic buildings.

Working Principle of Mortar Spraying Machine

The automatic mortar spray machine is a special coating equipment using spraying technology. The principle is to control the airflow to instantly push the air distribution reversing device to reverse so that the piston of the air motor can make a stable and continuous reciprocating motion. The automatic mortar sprayer pressurizes the sucked paint and transports the paint to the spray gun of the sprayer through a high-pressure hose, and the spray gun instantly atomizes the paint and releases it to the surface of the object to be coated. The spraying machine is mainly composed of a feeding device, a spray gun, and an atomization source.

Operation Tips for Mortar Spraying Machine

Attention Before Starting up
The operator needs to press the Deep Well pump several times before starting the machine. It is necessary to fill the transmission part to ensure better lubrication and reduce friction in the running part.

Power Supply Precautions
The operating personnel need to do a lot of inspections after the power supply is turned on. For example, check whether the rubber spiral direction is consistent. If the operation finds inconsistency, it needs to be performed. Change the power phase line in time.

Attention After Spraying
The operating personnel also need to pay attention to discharge the remaining materials after the completion of the operation of the Mortar Spraying Machine. Inject water into the hopper to clean the hopper, so that the hopper can be kept clean. the sprayed area should be infiltrated with water before plastering. The nozzle should be vertically and sprayed as far as possible (distance can be adjusted according to the spraying effect), and evenly sprayed, and coordinated with the leveling process. If the wall is too dry or sprayed for too long, it will seriously affect the leveling effect and change the process.

Factors to Consider Before Choosing a Mortar Spraying Machine

Project Requirements
Assess the specific needs of your project. Consider factors such as the type of material to be sprayed (e.g., cement mortar, plaster, texture coatings), the area to be covered, the desired spraying distance, and the required output per hour or day. Understanding your project requirements will help you choose a machine that can meet these needs effectively.

Spraying Method
There are different spraying methods available, such as rotor/stator, piston, or screw-type pumps. Each method has its advantages and is suitable for specific materials and applications. Evaluate the material you will be spraying and choose a machine that is compatible with it. Consider factors such as the viscosity of the material and the desired texture or finish.

Power Source
Mortar spraying machines can be powered by electricity, compressed air, or diesel engines. Consider the availability of the power source at your project site and choose a machine that aligns with it. Electric machines are commonly used for indoor applications, while compressed air or diesel-powered machines offer more mobility and are suitable for outdoor projects or areas without electricity.

Pressure and Flow Rate
Evaluate the required pressure and flow rate for your project. The pressure and flow rate determine the spraying distance, coverage, and efficiency. Ensure the machine you choose can provide the necessary pressure and flow rate to achieve the desired results. Consider the adjustable pressure and flow rate options available on the machine.

Mobility and Portability
Assess the mobility requirements of your project. If you need to move the machine frequently or work on different areas of the site, consider a machine that is portable and easy to transport. Look for features such as wheels, handles, or lightweight designs that facilitate maneuverability.

Ease of Operation and Maintenance
Consider the ease of operation and maintenance of the machine. Look for user-friendly controls, adjustable settings, and clear instructions. Consider the cleaning and maintenance procedures required for the machine. Choose a machine with accessible parts that are easy to clean and maintain.

Quality and Durability
Select a mortar spraying machine from a reputable manufacturer known for producing high-quality and durable equipment. Research the manufacturer's reputation, read customer reviews, and consider the warranty provided. A reliable machine will perform better, have a longer lifespan, and require fewer repairs or replacements.

Budget
Consider your budget and compare prices from different suppliers. However, keep in mind that choosing the cheapest option might compromise the quality and performance of the machine. Balance your budget with the features, quality, and durability offered by the machine.

Ultimate FAQ Guide to Mortar Spraying Machine

Q: How does a mortar spraying machine work?

A: The working principle of the mortar spraying machine is to use the air compressor to drive the abrasive (or projectile) to the workpiece surface to achieve rust removal, painting, and decorative treatment.

Q: What is a mortar sprayer?

A: The mortar sprayer is a kind of coating equipment that mainly disperses the mortar into a mist and then sprays it on the surface of the object. The mortar sprayer can be used to spray various materials such as concrete, mortar, and especially, putty. It mainly links the pipeline through materials such as screw pumps and plunger pumps. The material is transported to the front end of the equipment, and then the material is blown away by high-pressure gas and sprayed on the surface of the object.

Q: What is the difference between a concrete pump and a mortar sprayer?

A: 1. Purpose
Concrete Pump is primarily used for transferring liquid concrete from a concrete mixer to the construction site. It is commonly used in large construction projects such as high-rise buildings, bridges, and large-scale infrastructure. Mortar Sprayer is designed for the application of mortar, plaster, stucco, or similar materials onto surfaces. It is used for tasks like plastering, rendering, and finishing on walls, ceilings, and other structures.
2. Material Type
Concrete Pump is designed to handle and pump liquid concrete, which is a mixture of cement, water, aggregates, and often additives. Mortar Sprayer is designed to handle mortar or plaster materials, which typically consist of cement, sand, and water, with or without additional additives.
3. Construction Scope
Concrete Pump is commonly used in large-scale construction projects where a significant volume of concrete needs to be transported over long distances and at different heights. Mortar Sprayer is suitable for a wide range of construction and renovation projects, including residential and commercial buildings, where the application of plaster or mortar is required.

Q: What is the theoretical maximum output of the Mortar Spraying Machine?

A: About 4-8 m3/h.

Q: What is your main product?

A: Trailer concrete pumps, concrete mixer pumps, truck concrete pumps, truck concrete pump booms, wet shotcrete machines, concrete placing booms, concrete mixers, concrete mixer trucks, concrete mixing plants, etc.

Q: Which spray pump is more efficient?

A: Currently the most popular spray pump is a mechanical screw spray pump. It can improve efficiency, reduce labor intensity and ensure the quality of the project is to develop in the direction of plastering construction.

Q: What types of mortar pumps are there?

A: Conventional mortar pumps, according to the different structural features can be divided into a plunger pump mortar, mortar diaphragm pump, squeeze type mortar pump, screw pump, and the like.

Q: What injection pressure is appropriate?

A: Injection pressure can be controlled at 0.15 ~ 0.2MPa. If the pressure is too small and the impact is not enough, the bond strength will be affected, resulting in mortar flowing.

Q: Does the Mortar Spraying Machine need to be cleaned every day?

A: Yes. You should use a scrub pad and scrub off any mixture that has set. If you allow it to set longer, it will probably never come off.

Q: What is spray plaster used for?

A: Interior Walls and Ceilings:
Spray plaster is commonly used to create smooth and even surfaces on interior walls and ceilings. Its efficient application method is well-suited for covering large areas, especially in commercial or industrial settings.
Commercial Spaces:
Spray plaster is often used in commercial spaces like offices, retail stores, and malls where speed is important, and a polished finish is desired. It can help reduce construction timelines and minimize disruption to business operations.
Residential Construction:
In residential construction, spray plaster can be used to finish walls and ceilings, particularly in larger homes or multi-unit developments. It can help speed up the construction process and ensure a consistent finish.
Renovations and Remodeling:
Spray plaster can be beneficial for renovations and remodeling projects where existing walls need to be repaired or covered with a new layer of plaster. Its efficiency can help minimize disruption for homeowners.
Hospitals and Healthcare Facilities:
Spray plaster's fast application method is advantageous in healthcare settings where construction work needs to be completed quickly to minimize disturbances to patient care.
Hotels and Hospitality:
For hotels, resorts, and other hospitality spaces, spray plaster can be used to create elegant and uniform interiors in a shorter time frame, allowing these establishments to open their doors sooner.
Industrial Buildings:
Spray plaster can be applied in industrial settings to create smooth and hygienic surfaces on walls and ceilings. It can also be used for fireproofing and thermal insulation.
Exterior Surfaces:
While less common, spray plaster can also be used on exterior surfaces such as facades. Some specialized formulations of spray plaster are designed for outdoor use.
Decorative Finishes:
Spray plaster may be used as a base layer for decorative finishes like paint, wallpaper, or texture coats. It provides a smooth foundation for these decorative treatments.

Q: How to choose the right Mortar Spraying Machine?

A: When selecting a spray plastering machine, consider factors such as the project scale, plaster mixture, and desired application speed. Consulting with experts and suppliers can help you choose a machine that aligns with your specific requirements.

Q: What is the difference between spray plaster and manual plastering?

A: Spray plastering provides faster results and reduces labor compared to manual plastering. It is also preferred for achieving a thinner and smoother surface.

Q: How should I maintain a plaster spray machine?

A: Regular maintenance of a plaster spray machine is important. Following the periodic maintenance steps outlined in the machine's user manual and cleaning the filters will enhance its performance and lifespan.

Q: Can a mortar spraying machine be used for both indoor and outdoor applications?

A: Yes. Our mortar spraying machine is suitable for indoor and outdoor wall spraying.

Q: What is the distance that a mortar spraying machine can spray mortar?

A: The horizontal distance can reach 100 meters and the vertical height is 50 meters.

Q: What are the safety precautions when using a mortar spraying machine?

A: Make sure to wear protective gear such as eye and ear protection, as well as a safety hat. Additionally, ensure that the area being sprayed is well-ventilated to minimize the risk of inhaling dust and fumes.

Q: Can a mortar spraying machine work with different nozzle sizes?

A: Yes. The different nozzle aperture sizes can meet your needs for different effects and different scenes.

Q: What are the advantages of using a cement mortar spray?

A: Efficiency
The machine can spray a large surface area in a short amount of time, reducing the time required to complete a project.
Quality
The machine can deliver a consistent and even application of cement mortar, ensuring a high-quality finish.
Safety
The machine eliminates the need for manual application of cement mortar, reducing the risk of accidents and injuries.
Cost-Effective
The machine can help reduce labor costs while increasing productivity and efficiency.
Flexibility
The machine can be used with a variety of cement mortar mixes and can adjust to different pressures and flow rates.

Q: What are the Benefits of Concrete Repairs by Machine Application?

A: Machine-applied concrete repair is ideal for projects with high repair volumes. The cost efficiency is much better than application by hand and the quality of the hardened repairs is more homogeneous, especially in overhead applications. Machine application of repair mortars therefore not only brings the benefits of increased output, but also helps to improve the repair durability. Machine application should be selected over manual application whenever the economic and environmental conditions are appropriate.

Q: How to operate the mortar wall plaster machine?

A: ● Turn on the power, press the button, and the screw pump will start to work. If the steering is reversed, adjust the power supply after pressing the stop button to stop, and change the steering, and there will be no material in the reverse direction.
● Inject a small amount of water into the inlet of the conveying hose, or use a screw pump to pump water to wet the conveying hose, and gradually discharge the water in the pipe from the outlet.
● Put the uniformly stirred material into the hopper, press the start button, and the spraying work can start, and the spraying quality can be adjusted by adjusting the air volume.
● Stirring materials must be continuously added to the hopper so that the gypsum can be sprayed continuously.
● After the spraying is completed, the material in the hopper should be sprayed before stopping the machine. Remove the spray head take the parts apart and clean them one by one.
● Pour 50 kg of clean water into the hopper, start the pump to clean it, and when clear water flows out of the nozzle, remove the delivery hose and roll it up.

Q: How does a plastering machine work?

A: Let's get into how a spray plaster machine really works. Construction generally is considered to have a long turnaround time. In order to reduce this, we need to perform the highest output with minimum cost. This means accuracy, precision, quality and cycle time must be optimised and the way to do this is through automating our systems. In other words, increase your output and quality through a wall plastering machine. Traditionally a plasterer would mix his plaster and apply it to walls with a hawk and trowel, then finish by ruling and smoothing. Back breaking and time-consuming work, right?
A machine will mix and pump ready mix dry bagged material into wet plaster which can then be sprayed. A simple drop of the bag over the grate, set your water consistency and you're off. No manual mixing and carrying wet plaster to the working area. The machine will also steadily create a consistent mixture with a fixed ratio of material to water. This means an even mixture across a whole house or even multiple houses as the machine regulates the mix. A spray plaster machine uses rotor and stator pump technology to ensure a continuous flow of material. A hose carries the material to the wall to be sprayed. Finally, the material is sprayed onto the wall using air projection in the spray gun.

Q: How to choose the right plaster machine?

A: Project Size and Scope:
The size and scope of your project play a vital role in determining the type of plaster machine you require. For smaller projects or areas that require spot plastering, a portable and compact machine would be suitable. On the other hand, larger projects demand powerful and high-capacity machines that can handle continuous plastering over extended periods. Assessing your project's size and scope will help you narrow down your options and choose a machine that aligns with your requirements.
Type of Plastering Material:
Cement plastering is the most common type of plastering used in construction. However, different plaster machines may be designed to handle specific materials. Some machines are optimized for cement-based plasters, while others can accommodate a variety of materials such as lime, gypsum, or even epoxy-based plasters. Ensure that the machine you choose is compatible with the plastering material you intend to use, as this will greatly affect the quality and durability of the plastered surface.
Performance and Output:
Consider the performance and output capabilities of the plaster machine you are evaluating. Look for features such as adjustable flow rates, pressure controls, and nozzle options, as these factors contribute to achieving the desired plaster thickness and texture. A machine with high output rates will help you complete your project efficiently, reducing labor costs and minimizing project timelines.
Ease of Use and Maintenance:
A user-friendly plaster spray machine can significantly impact the overall efficiency of your project. Look for machines with intuitive controls, easy setup procedures, and straightforward maintenance requirements. A machine that is easy to operate and maintain will not only save you time but also reduce the risk of errors or downtime during your plastering activities.
