Ready Mix Concrete Pump Truck

Our ready-mix concrete pump truck is a specialized vehicle designed to transport and pump pre-mixed concrete to construction sites. The ready-mix concrete is prepared at a concrete batching plant and delivered to the site using the pump truck, which allows for precise and efficient concrete placement. These trucks combine the functions of transporting and placing concrete in hard-to-reach areas, reducing the need for manual labor and improving construction speed.



Key Features of a Ready Mix Concrete Pump Truck:

Combination of Two Functions:

The truck combines a ready-mix concrete drum (which continuously mixes the concrete during transport) with a concrete pump that is equipped with a boom arm or flexible hoses. This means that not only does the truck transport the concrete, but it also pumps the concrete to the required location on the job site.



Truck-Mounted Boom:

The boom is an extendable arm that can reach great distances and heights. It is typically articulated, meaning it can be extended and adjusted in multiple directions. Boom lengths on ready-mix pump trucks typically range from 28 meters (92 feet) to 56 meters (183 feet), though some models can go even higher (up to 70 meters or more).

The boom allows the concrete to be pumped directly into the forms, reducing the need for laborers to move heavy materials by hand or wheelbarrow.



Ready-Mix Concrete Delivery:

The truck carries ready-mix concrete in a rotating drum, which ensures that the concrete remains mixed during transportation, preventing the material from setting prematurely.

The drum usually rotates at a constant speed to keep the concrete fluid and prevent it from hardening before it reaches the job site.



High Concrete Output:

Ready mix concrete pump trucks are designed to handle high-output pumping. The typical pumping capacity of a ready-mix concrete pump truck can range from 80 to 150 cubic meters per hour (about 105 to 195 cubic yards per hour).

Some high-performance models are capable of pumping at rates up to 200 cubic meters per hour (260 cubic yards per hour), making them ideal for large-scale projects that require continuous pouring.



Efficient Concrete Placement:

The boom arm allows for precise placement of concrete in hard-to-reach areas such as multi-story buildings, high-rise apartments, or construction sites with limited access.

The truck can deliver and pump concrete over obstacles, such as walls, other buildings, or structures that block access, which would be difficult or time-consuming with a regular concrete truck and manual labor.



Multiple Functionality:

The truck can serve multiple purposes: transport and deliver concrete, as well as pump it to specific locations without the need for additional labor or equipment. This is particularly beneficial for complex sites with limited space for equipment.

Hydraulic System:

Ready-mix concrete pump trucks use a hydraulic system to control the boom's extension, elevation, and rotation. The hydraulic system allows for smooth operation and precise control, especially when positioning the boom in confined or elevated areas.



Our Product advantage

High delivery pressure for demand of high-rise and long distance projects;

Air cooling system, without dependence of external water;

PLC system to ensure best control performance;

With re-pumping function to smooth construction of better accessibility;

Equipped with wired remote controller, easy to operate.



Our Product parameter(specification)

MODEL: HBT60-13-75S/130RS
Max theoretic output					68m³/h
Max concrete pumping pressure					7-13 Mpa
High and low valtage switchover					Yes
Hydraulic system					Double pump & double circuit opening
Main oil pump discharge					224ml/r(kawasaki)
Hydraulic system pressure					32MPa
Power supply					Electric motor	Diesel motor
Voltage					380V	/
Motor power					75KW	130KW
Motor speed					2100r/m
Distribution valve type					S pipe valve
Concrete conveying cylinder bore/stroke					Ф200/1650mm
Oil cylinder bore/stroke					Ф125/1650mm
Max aggregate size					40mm
Hopper Volume					600L
Feeding height					1450mm
Max delivery vertical distance					130m
Max delivery horizontal distance					400m
Concrete slump					160-230mm
Hydraulic oil tank volume					420L
The radiator cooling type					Air cooling system
Hydraulic pump type					Ram pump
Outer dimensions(L*W*H)					6100×2000×2130mm
Total weight					5500 kg

Applications of Ready-Mix Concrete Pump Trucks

High-Rise Buildings:

Pump trucks can deliver concrete to the upper floors of high-rise buildings, making them ideal for skyscraper construction.

Bridges and Tunnels:

For large-scale infrastructure projects, pump trucks can transport concrete to locations that are difficult to access, such as tunnels or bridge columns.

Foundations and Slabs:

Ready-mix concrete pump trucks are commonly used for pouring concrete foundations, slabs, and other structural elements in residential and commercial construction projects.

Residential and Commercial Projects:

Pump trucks are also used in residential projects for tasks such as concrete driveways, patios, and sidewalks, as well as commercial applications like warehouses or parking structures.

Specialized Construction:

They are used for large-scale industrial projects, such as dams or reservoirs, where large volumes of concrete need to be delivered efficiently.







How many Types of Ready-Mix Concrete Pump Trucks we can offer?

Boom Pump Trucks:

These trucks feature an extendable boom that can reach high elevations or long horizontal distances. The boom is made of multiple sections that can fold and extend, making it easy to maneuver around obstacles.

Line Pump Trucks:

These trucks use a series of hoses or pipes to deliver the concrete. They are more suitable for projects that don't require a long reach, such as ground-level pours or horizontal work. The line pump can handle more flexible routing around obstacles.



Company advantage

We have first-class production line and strict quality management.

We have professional team to provide comprehensive one-stop service for you.

We could give customers the most competitive price to meet you budget.

We have big production capacity to guarantee fast delivery and on-time shipment.
